| Table-W | 18.125" | 460.37 mm |
| Table-L | 96.468" | 2,450.3 mm |
| Travel-Long | 51.188" | 1,300.2 mm |
| Travel-Cross | 15.75" | 400.05 mm |
| Power | 30 hp | 22.4 kW |
| RPM | 1,800 RPM | 1,800 RPM |
| Taper | 50 | 50 |
18 1/8" X 96 15/32" TABLE
23 SPINDLE SPEEDS 18 - 1800 RPM
32 FEEDS 3/8-84 IPM ,VERT 1/4 OF SAME
RAPID FEED
51 3/16" X TRAVEL
15 3/4" Z (KNEE) TRAVEL
15 3/4" Y TRAVEL
5 7/8" HEAD TRAVEL
#50 TAPER SPINDLE
POWER DRAW BAR
COOLANT SYSTEM
WORK LIGHT
22 KW/30 hp MAIN MOTOR
weight approx. 19,400 lb
