200 ton Komatsu Metal Stamping Servo Press Model H2F200, Year 2003!
| Tonnage | 220 T | 199.581 t |
| Stroke | 7.8" | 198.12 mm |
Tonnage: 220
Stroke: 7.87 inches
Shut Height: 31.63 inches
Adjustment: 3.94 inches
Bed Size: 72.8 x 37.4
Ram Area: 72.8 x 33.5
SPM: 48-88
Standard SpecificationsKomatsu Servo Press Model H2F200Servo Metal Stamping Press200 ton Metric Capacity220 ton US Capacity1.3" to 7.87" Variable Stroke3.94" Motorized Adjustment31.63" Shut Height Over Bed22.63" Shut Height Over Bolster72.83" x 37.4" Bed Area72.83" x 33.5" Slide Area48-88 Variable Strokes per Minute Equipment and Features Recirculating Lube SystemHydraulic OverloadsPlunger Guided SystemHigh Torque Gear Box with AC Servo MotorsUser Friendly press Operation Systems9.06" T-Slotted BolsterQuick Die Change System35" Wide Windows40" Floor to top of bolsterLoad MonitorJob Memory : 100 jobsDie ProtectionFloor Standing Overall Height 15' 9" TallWeight: 88,000 lbs.This Komatsu Servo Press is in EXCELLENT CONDITON and Can be seen under power in the S&G Press Warehouse upon request!200-ton Servo Press For Metal Stamping Operations
SERVO Press
