10000 Lbs. PERFECTO Servo Feed Line, 14" @ .250" Capacity
Coil Weight: 10000 pounds
Coil Width: 14 inches
Coil Thickness: .250 inches
Specifications:Coil weight capacity: 10,000 Lbs.Coil width capacity: 14"Stock thickness capacity: .250" @ 14" WideI.D. Expansion range: 20" AdjustableCoil OD capacity: 60"Serial No.: SS-91086Equipped With:Double End Coil Reel Model No. DR100-14Three leaf mandrelsHydraulic mandrel expansion Thread drives for jog forward and reversePowered mandrel rotation (indexing) Air brakes mounted on main spindles Adjustable tensioningCoil hold down arms with motorized end wheel Coil loading car with powered lift and travel Powered Straightener Model No. 38-14-7Entry and exit pinch rolls with air operated adjustmentsSeven straightening rolls x 3.8" diameterMotorized individual upper straightening roll adjustmentsStock peeler table with extension Stock end de-bender Heavy duty hand crank edge guidesVariable speed drive system Automatic lubrication system Exit cascade loop support rollersUltrasonic variable speed loop controlExit Thread Table Model No. ETT-14Bomb-Bay Door styleServo Roll Feed Model No.: 600-14 / Serial No.: E6Six inch diameter upper and lower feed rollsMatte chrome finish on feed rolls Air operated upper roll adjustment/pilot Solenoid controlled pilot release Dual adjustable edge guides - motorizedAnti back up roll - air operated Centralized lubrication pointsPress mounted INDRAMAT AC servo drive and controls
