2021 DOOSAN DVF 5000 5 Axis VMC, equipped with a Siemens 840D Control, 18000 RPM spindle, 60 ATC, HSK 63, and Renishaw NC4 Laser Tool Setter. X/Y/Z Travel: 24.6"/17.7"/15.7". Max table capacity: 882 lbs. and LNS chip conveyor. Includes MICRON paper band filtration system. THIS SYSTEM CAN BE USED FOR MULTIPLE MACHINES, AND CAN BE CENTRALLY LOCATED ANY PLACE WITHIN THE SHOP
ONLY 690 CUT HOURS!
| X Travel | 24.6" | 624.84 mm |
| Y Travel | 17.7" | 449.58 mm |
| Z Travel | 15.7" | 398.78 mm |
| Spindle Speed | 18000 rpm | 18,000 RPM |
| Tool Capacity (ATC) | 60 | 60 |
| Table Size (W) | 19.7" | 500.38 mm |
| Table Size (L) | 17.7" | 449.58 mm |
| Main Spindle Motor | 29.5 hp | |
| Spindle Taper | HSK 63 | HSK 63 |
| 4th Axis Rotary Table Size | 19.7" | 500.38 mm |
| Coolant Thru | Yes | Yes |
| Coolant Thru High Pressure | Yes | Yes |
| Tool Probe/Auto Tool Length Measurement | Yes | Yes |
| Rapid Traverse Rates: X Axis Y Axis Z Axis | 1575 IPM/ 1575 IPM/ 1575 IPM/ | 1575 IPM/ 1575 IPM/ 1575 IPM/ |
| Control | CNC (SIEMENS 840D CONTROL) | CNC (SIEMENS 840D CONTROL) |
| Dimensions | 114" X 114" X 87" | 114" X 114" X 87" |
| Weight | 16,534 lbs | 16,534 lbs |
CUTTING FEED RATE 0.4 - 787 IPM
MAX TABLE CAPACITY 882 LBS
SIEMENS 840D CONTROL
18,000 RPM SPINDLE
60 ATC
HSK 63
PAPER BAND FILTRATION
RENISHAW NC4 LASER TOOL SETTER
LNS TURBO SUPER FINE COMPACT LEFT HAND CHIP CONVEYOR
