Minster 15,000 LB. X 26" X .35" Servo Feed Line
MEF5-26S SINGLE ROLL ELECTRIC FEED (S/N 18-50670)
Minimum Feed Line Over Floor: 52"
Maximum Feed Line Over Floor: 61"
Feed Roll Diameter: 5.392"
Maximum Stock Width: 26"
Minimum Stock Thickness: 0.020"
Maximum Stock Thickness: 0.250"
Maximum Thickness at Full Width: 0.125"
Maximum Width at Full Thickness: 16"
Roll Opening for Threading: 0.47"
MTT12-26S THREADING TABLE (S/N 13-81147)
Length of Table: 12'
Maximum Stock Width: 26"
MSH30-26-7 STRAIGHTENER (S/N 13-50392)
Maximum Strip Thickness: 0.350"
Minimum Strip Thickness: 0.020"
Maximum Strip Width: 26"
Maximum Width at Maximum Thickness: 5"
Maximum Thickness at Full Width: 0.140"
Line Speed: 40 - 1200 IPM
MR15-26S SINGLE REEL (S/N 13-70452)
Coil Weight, Maximum on Center: 15,000 lbs
Coil Width, Maximum: 26"
Coil I.D. Range: 20" - 24"
Coil O.D. Maximum: 60"
Coil Load Position: Operator Side
