SERIAL ..................... 23635
MODEL ...................... SS-6
TONNAGE .................... 60
STROKE ..................... 5"
ADJUSTMENT ................. 2.75"
SHUT HEIGHT ................ 14.5"
SPEED ...................... 90 SPM
BED BOLSTER ................ 32" X 21" X 2-1/4" HIGH
BOLSTER T-SLOTTED .......... YES
RAM SIZE ................... 15" WIDE (EARS) X 12"
PASSLINE ................... 36"
DISTANCE IN REAR HOUSINGS .. 15"
TYPE ....................... FLYWHEEL
AIR CLUTCH & BRAKE ......... YES
CONTROLS ................... RUN / JOG
FOOT TRIP .................. YES
AUTO LUBE .................. YES
MOTOR ...................... 5 HP
Specifications
