| Swing | 24" | 609.6 mm |
| Machining Length | 82" | 2,082.8 mm |
| # Axis | 3 | 3 |
| Chuck Size | 20" | 508 mm |
| Bar Capacity | 7.1" | 180.34 mm |
| Power | 30 hp | 22.4 kW |
| Max RPM | 1,000 RPM | 1,000 RPM |
| Turning Dia | 22.8" | 579.12 mm |
| Tailstock | Yes | Yes |
| Control | CNC | CNC |
| Dimensions | 94.5" X 203" | 94.5" X 203" |
| Weight | 14740 | 14740 |
MAZAK FUSION 640T CONTROL
10.4" COLOR LCD
EIA/ISO OPTIONS PACKAGE
RE-THREADING
PCMCIA INTERFACE (2 SLOT)
NETWORK INTERFACE (FOR LAN & MODEM)
SPINDLE BORE 7.1" / 1000 RPM
8 DISK + 6 BORING TURRET
MANUAL TAILSTOCK
RELOACTION DEVICE
REAR MANUL CHUCK PRE (FOR 7.1" BORE)
M5N SIDE EXIT BEST STYLE CHIP CONVEYOR 80" UNIVERSAL
HI PRESSURE COOLANT 71 PSI / 5.3 GALLON
20" SCHUNK ROTA TB 500-230 AIR CHUCK
