55.1” X 26” X 25” Vertical Machining Center with Fanuc Series i Control, Marposs CSI60HI Tool Monitor, Chip Conveyor, Spindle Chiller, Coolant Tank & Pump.
| X | 1,400 mm | 55.118" |
| Y | 660 mm | 25.984" |
| Z | 635 mm | 25" |
| Power | 15 kW | 20.1 hp |
| RPM | 8,000 RPM | 8,000 RPM |
| # ATC | 24 | 24 |
| Taper | NT #40 | NT #40 |
| Table-W | 650 mm | 25.591" |
| Table-L | 1,600 mm | 62.992" |
| # Axis | 3 | 3 |
55.1” X 26” X 25” Vertical Machining Center with Fanuc Series i Control, Marposs CSI60HI Tool Monitor, Chip Conveyor, Spindle Chiller, Coolant Tank & Pump.GENERAL SPECIFICATIONS Table Size: 63” X 25” Table Capacity: 2,866 LbsX - Axis Travel: 55.1”Y - Axis Travel: 26”Z - Axis Travel: 25”Rapid Traverse Rate (X/Y/Z): 1417/1417/1260 IPMSpindle Taper: CAT 40 Big PlusSpindle Speed: 8,000 RPMMain Motor: 20 HPTool Changer Capacity: 30Coolant Thru Spindle: YesMachine Dimensions: 138” X 101” X 111”Machine Weight: 21,000 LbsINCLUDES: Fanuc Series i Control, Marposs CSI60HI Tool Monitor, Chip Conveyor, Spindle Chiller, Coolant Tank & Pump.
