USED 2017 HAAS ST-40

Overview
Manufacturer:
HAAS
Model:
ST-40
Year:
2017
Stock #:
5371
Status:
For Sale
Description

25.5” X 44” CNC Turning Center with Haas CNC Control, 2-Speed Gearbox, Extra Performance Option (55 HP), 3-Jaw Byson Hydraulic Chuck, Programmable Tailstock, Tool Presetter, Chip Conveyor, Extended Tool Pocket, Remote Jog Handle, Rigid Tapping and USB Port.

Specifications
Swing34.5"876.3 mm
Machining Length1,118 mm44.016"
# Axis22
Chuck Size15"381 mm
Bar Capacity4"101.6 mm
Power40 hp29.8 kW
Max RPM2,400 RPM2,400 RPM
Turning Dia25.5"647.7 mm
TailstockNoNo

25.5” X 44” CNC Turning Center with Haas CNC Control, 2-Speed Gearbox, Extra Performance Option (55 HP), 3-Jaw Byson Hydraulic Chuck, Programmable Tailstock, Tool Presetter, Chip Conveyor, Extended Tool Pocket, Remote Jog Handle, Rigid Tapping and USB Port.GENERAL SPECIFICATIONS Max. Swing:                            34.5”Max. Cutting Diameter:                    25.5”Max. Cutting Length:                    44”X - Axis Travel:                        17”Z - Axis Travel:                        44”Chuck Size:                            15”Bar Capacity:                            4”Spindle Bore:                            4.6”Spindle Nose:                        A2-8Spindle Motor:                        55 HPSpindle Speed:                        2,400 RPMTurret Position:                        12Turret Type:                            Bolt-OnINCLUDES: Haas CNC Control, 2-Speed Gearbox, Extra Performance Option (55 HP), 3-Jaw Byson Hydraulic Chuck, Programmable Tailstock, Tool Presetter, Chip Conveyor, Extended Tool Pocket, Remote Jog Handle, Rigid Tapping and USB Port.
