16” X 25” Automatic Horizontal Bandsaw with Automatic PLC Controller, Multi-Indexing Up to 33” in a Single Stroke, Power Driven Angle Adjustment, Bundle Clamping, 7.5 HP VFD True Direct Blade Drive, Hydraulic Positive Down Feed, Automatic Chip Removal Auger, Coolant System and Unist Blade Coolant Mister
Rect-Cap (H) | 16" | 406.4 mm |
Rect-Cap (W) | 25" | 635 mm |
Rounds-Cap | 16" | 406.4 mm |
Power | 7.5 hp | 5.6 kW |
Blade Width | 1.25" | 31.75 mm |
Blade Length | 222" | 5,638.8 mm |
16” X 25” Automatic Horizontal Bandsaw with Automatic PLC Controller, Multi-Indexing Up to 33” in a Single Stroke, Power Driven Angle Adjustment, Bundle Clamping, 7.5 HP VFD True Direct Blade Drive, Hydraulic Positive Down Feed, Automatic Chip Removal Auger, Coolant System and Unist Blade Coolant MisterGENERAL SPECIFICATIONS Rectangle Capacity: 16” X 25”Round Capacity: 16”Round Capacity at 45°: 16”Round Capacity at 30°: 11”Bundling Capacity: 16” X 25”Blade Size: 1-¼” X 18’ 6”Blade Drive: 7.5 HPBlade Speeds: 50 - 350 SFMBlade Wheel Diameter: 19”Shuttle Stroke: 0 - 33”Workload: 8,000 LbsElectrical: 480V / 3 PHApprox Shipping Weight: 7,500 lbsApprox Shipping Dimensions: 128” X 96” X 91”INCLUDES: Automatic PLC Controller, Multi-Indexing Up to 33” in a Single Stroke, Power Driven Angle Adjustment, Bundle Clamping, 7.5 HP VFD True Direct Blade Drive, Hydraulic Positive Down Feed, Automatic Chip Removal Auger, Coolant System and Unist Blade Coolant Mister
