This machine is under power and can be inspected. A factory-trained technician can be provided at extra cost for installation & operator training.
| Max Profile Width | 43.3" | 1,099.8 mm |
| Minimum Profile Width | 2" | 50.8 mm |
| Max Profile Height | 18" | 457.2 mm |
| Minimum Profile Height | 34" | 863.6 mm |
| Number of Spindles | 3 Spindles 1-Per Drilling Axis | 3 Spindles 1-Per Drilling Axis |
| Spindle Power | 25 hp | 18.6 kW |
| Spindle Speed | 0 RPM | 0 rpm |
| Machine Hours | 11587 | 11587 |
| Control | CNC (Siemens CNC Control) | CNC (Siemens CNC Control) |
Specifications DG-1250 Double Miter Band Saw :
Maximum 90° Cut Dimensions: 49” × 20”
Maximum 45° Cut Dimensions: 31” × 20”
Maximum 30° Cut Dimensions: 21” × 20”
Maximum 90° Round Dimensions: 24”
Drive Motor: 20 HP
Saw Blade: 394” x 2.64” x .063”
Machine Weight: 14,660 lbs
39'-9" on the outfeed transfers
64' of conveyor from the face of the drill to the end of the outfeed conveyor
23' from the back of the drill to a wall on the conveyors
43'-6" conveyor outside
25' transfer outside
