NEW Siemens CNC Control System
Manufacturer: Waldrich Siegen
Model: DH 1600/35 x 12000
Condition: Used
Stock Number: 10733
Retrofit: 2021
Between centers: 12,000 mm
Capacity between centers: 35 Ton
Swing over slide: 1,600 mm
Chuck diameter: 1,200 mm
Tailstock diameter: 360 mm
Power at main spindle/headstock: 136 kW
Chuck speed: 1 - 240 rpm
Step 1: 1 - 60 rpm
Step 2: 4 - 240 rpm
Base speed: 15 rpm
Max work piece length: 11,800 mm
Clamping area outside, min - max: 105 - 1,000 mm
Number of clamping jaws: No. 4
Max torque at face plate: 80,000 Nm
Center angle: 60 Degree
No. of carriages: No. 1
Travel way - z axis: 13,500 mm
Travel way - x axis: 700 mm
Traverse x axis: 0 - 4,500 mm/min
Traverse z axis: 0 - 4,500 mm/min
Rapid traverse x, z axes: 4,500 mm/min
Clamping area: 125 - 650 mm
Movement of quill: 100 mm
No. of steadies: 2
Number of quills: No. 3
Rapid traverse: 2,150 mm/min
Machine length: 20,000 mm
Machine width: 5,000 mm
Machine height, above floor level: 2,400 mm
Machine weight: 105 Ton
