Year: 1985
Condition: Used
Stock Number: 10129
1st stage: 2,500 kN
2nd stage: 5,000 kN
3rd stage: 8,000 kN
Rated force of hydraulic cushion: 2,500 kN
Travel of the cross-piece (drawing & clamping): 1,700 mm
Maximum distance between table & drawing cross-piece: 2,600 mm
Table dimensions: 2,650 x 2,650 mm
Idle run: 200 mm/s
Backstroke: 200 mm/s
Working stroke for double action: 32 mm/s
Working stroke for single action: 10 mm/s
Rated pressure: 20 MPa
Total installed power of all electric motors: 299.5 kW
Dimensions of the press (l x w x h-above the floor): 15.22 x 8.62 x 7.73
