The FADAL 6030 Model 907-1 Vertical Machining Center (CNC) is a used high-capacity CNC milling machine engineered for precision, rigidity, and versatility in demanding machining applications. With an expansive 60" x 30" x 30" travel, powerful 15 HP spindle motor, and a robust 20-position automatic tool changer (ATC), this VMC delivers efficient operation and high throughput for both one-off and production-level tasks. Designed around the reliable CAT 40 taper and offering a 3,300 lb table load capacity, the FADAL 6030 is well-suited for shops handling large components and complex part geometries.
| CNC Control | CNC 88HS | CNC 88HS |
| # Axis | 3 | 3 |
| Table-L | 62.5" | 1,587.5 mm |
| Table-W | 30" | 762 mm |
| Max Table Load | 3300 | 3300 |
| X-axis Travel | 60" | 1,524 mm |
| Y-axis Travel | 30" | 762 mm |
| Z-axis Travel | 30" | 762 mm |
| Rapid Traverse Rate (X/Y/Z) | 400IPM | 400IPM |
| Spindle Taper | CAT 40 | CAT 40 |
| Spindle Speed | 0 RPM | 0 RPM |
| Main Motor | 15 hp | 11.2 kW |
| # ATC | 20 | 20 |
| Machine Dimensions | 159118000 | 159118000 |
| Machine Weight | 17000 | 17000 |
| Dimensions | 164″ x120″ x 126″ (Shipping) | 164″ x120″ x 126″ (Shipping) |
| Weight | 17000 | 17000 |
X-Axis Travel: 60”
Y-Axis Travel: 30”
Z-Axis Travel: 30”
Rapid Traverse (X, Y, Z): 400 IPM
Table Size: 30” x 62.5”
Max Table Weight: 3,300 LB
Spindle Nose to Table: 5.5” – 35.5”
Spindle Motor: 22.5 HP
Spindle Speed: 10 – 10,000 RPM
Spindle Taper: CAT 40
Auto Tool Changer: 20
