STANDARD FEATURES
Axles: 2 – 23,000lbs spring ride.
Brakes: Air brakes.
Tires: 235/75R17.5 Dual wheel 8 bolt rim
Jack: 2 – 12,000lbs drop leg, 2 speed jacks.
Coupler: 3” Pintle flat face 4 bolt mount 66,000lb capacity.
Length: Deck length of 24′ and overall length of 41′
Dove Tail: Total length of 6 feet.
Ramps: 2 single flip over ramps.
Toolbox: 40” weatherproof box mounted under body on driver side.
Spare Tire: Full size spare mounted at front of trailer.
Load Securement: 4 sliding winches on pole bunks with 4” straps, front 4” winch and strap for belly wrapping.
Pole Bunks: 4 pole bunks with rubber pads.
Removable Bunks: Rear and middle bunk can be removed and stored at front of trailer.
D-rings: 8 flush mount D-rings installed in deck.
Rear Plug: 6 pole plug in rear for extending lights.
Rear Light Bar: Includes 35 feet of cable to mount at end of pole storage on trailer.
Chock Blocks: 2 sets of chock blocks with aluminum storage boxes.
Rear Strobe Lights: LED Strobe lights for added visibility for wide or long loads.
Reel Stands: 3 sets for locking reel stands with centering cones
Reel Capacity: Can hold 3,000lb reels up to 56” wide
Rub Rail: 2 x 8 removable sides with rub rail.
Winch Bar: Used to tighten yourwinch straps, this device just adds an extra layer of protection and securement for your cargo.
Scorpion Lined: Scorpion liner added to front of trailer for added durability.
Lighting: Equipped with high-quality LED marker, stop, turn, and backup lights for enhanced visibility.
Enclosed Solder-Sealed Wiring: All wiring is fully enclosed, solder-sealed, and shrink sealed, ensuring maximum protection and long-lasting reliability.
Safety Chains: ½” Grade 70 chains with slip hooks and safety latches for added security.
Trailer Breakaway Kit: The breakaway system is designed to safely stop the trailer in the event it becomes disconnected from the safety chains or ball mount, activating the trailer’s electric brakes in an emergency.
Trailer Plug: Cold-weather-rated 7-pole Semi-style plug for reliable performance in all conditions.
Reflective Markers: Reflective stickers and lights on the trailer for optimal visibility.
Lumber Decking: Constructed with high-quality, pressure-treated lumber for durability and longevity.
Certified Steel: Built with premium certified steel, ensuring enhanced strength and durability.
Powder Coat Finish: All trailers are sandblasted and powder-coated using a three-step process to provide a near-impenetrable, baked-on finish for superior durability and rust prevention.
Pin striping: Finished with custom pinstriping available in any preferred color for a personalized touch.
GVWR: 46,000 lbs
Ship Weight: 15,373 lb
