MORI SEIKI GV-503 5AX, 2001 vertical machining center with 5-axis capability. Features 24" X, 20.1" Y, 18.1" Z travel, 12000 rpm spindle speed, 30-tool capacity. Equipped with Mitsubishi MSG 805 control, probing, tool setter, and more.
| X Travel | 24" | 609.6 mm |
| Y Travel | 20.1" | 510.54 mm |
| Z Travel | 18.1" | 459.74 mm |
| Spindle Speed | 12000 rpm | 12,000 RPM |
| Tool Capacity (ATC) | 30 | 30 |
| Table Size (W) | 29.5" | 749.3 mm |
| Table Size (L) | 21.7" | 551.18 mm |
| Main Spindle Motor | 15 hp | |
| Spindle Taper | CAT 40 | CAT 40 |
| Spindle Nose To Table Top | 5.9" - 24.0" | 5.9" - 24.0" |
| 4 Axis Table Rotation | 1 Degree Index | 1 Degree Index |
| Part Probe | Yes | Yes |
| Tool Probe/Auto Tool Length Measurement | Yes | Yes |
| Control | CNC (MITSUBISHI MSG 805) | CNC (MITSUBISHI MSG 805) |
| Dimensions | 87.9" × 157" X 113.9" | 87.9" × 157" X 113.9" |
| Weight | 22,220 | 22,220 |
MITSUBISHI MSG 805 CONTROL
PROBING
TOOL SETTER
CENTER POINT SOFTWARE
INVERSE TIME FEED
ADDITIONAL OOL OFFSETS
CUSTOM FUSION 360 POST
