FIRST CNC Vertical Machining Center
Model MCV-2000
Year 2006
Control Fanuc 18i-MB
| X | 80" | 2,032 mm |
| Y | 45" | 1,143 mm |
| Z | 30" | 762 mm |
| Power | 20 hp | 14.9 kW |
| RPM | 15,000 RPM | 15,000 RPM |
| # ATC | 24 | 24 |
| Taper | BT40 | BT40 |
| Table-W | 86.5" | 2,197.1 mm |
| Table-L | 39.37" | 1,000 mm |
| # Axis | 3 | 3 |
| Control | CNC (Fanuc) | CNC (Fanuc) |
| Dimensions | 23’ x 13’ | 23’ x 13’ |
| Weight | 31,000 Lbs | 31,000 Lbs |
FIRST CNC Vertical Machining Center
Model MCV-2000
Year 2006
Control Fanuc 18i-MB
Technical Specifications (Subject to verification)
Travels
X-Axis 2050 mm (80")
Y-Axis 1150 mm (45")
Z-Axis 760 mm (30")
Spindle
Spindle Type BT-40
Max. spindle speed 120-15,000 rpm
Spindle motor 20HP (Continuous Rating)
ATC 24
Table
Table size 2200 mm x 1000 mm (86”-39.3")
Max. table loading capacity 3000 kgs (6600 Lbs)
Dimensions Floor area 7,000 x 4,000 mm (23’ x 13’)
Weight 14,000 Kg (31,000 lbs.)
Equipped with
• CNC FANUC Series 18i-MB
• Lift up chip conveyor
• MPG hand wheel
• Spindle Chiller
• Schneeberger linear roller guideways
