| Table Size-W | 18" | 457.2 mm |
| Table Size-L | 108" | 2,743.2 mm |
| Travel-Long | 63" | 1,600.2 mm |
| Travel-Cross | 16" | 406.4 mm |
| Travel-Vert | 21" | 533.4 mm |
| Power | 50 hp | 37.3 kW |
| RPM | 1,250 RPM | 1,250 RPM |
| Taper | 50 | 50 |
18" x 108" TABLE
16 SPEEDS 50-1250 RPM
#50 TAPER
SEPERATE RAPID & FEED MOTOR 5 HP
32 FEEDS 3/8 - 90 IPM
63" TABLE TRAVEL
16" CROSS TRAVEL
21" VERTICAL KNEE TRAVEL
ARBOR SUPPORT W/BRIDGE TO TIE ARBOR SUPPORT TO KNEE (see picture)
COOLANT SYSTEM
3 AXIS DIGITAL READOUT
FRONT OPERATED TABLE HANDLE
MOTOR: 50
ELECTRICS: 460 VOLT
96" X 136" WIDE X 78" HIGH
ELECTRIC PANEL 14"x26"x70"
ANILAM DIGITAL READOUT
