WELDON 1632 GOLD CNC CYLINDRICAL GRINDERMANUFACTUER: WELDONMODEL: 1632 GOLDCONDITION: USED CONDITIONBC3221-3151EYEAR: 1998SPECIFICATIONS:Swing Over Table – Maximum…………16″Distance between Centers – Maximum…………32″Workpiece Weight – Maximum between Centers…………1,200 Lbs.Workpiece Weight – Maximum Chucked…………700 Lbs.Work Diameter – Minimum using 10″ Diameter Wheel…………0″Table Travel…………32″Work Height above Floor…………46-1/2″Headstock:Motor…………2.5 HPProgrammable Speeds – Infinitely Variable…………0 – 320 RPMNon-programmable Speeds – Infinitely Variable…………0 – 600 RPMSpindle Nose…………A2-6″Thru-hole…………1-1/16″Center Taper…………Morse #5Wheelhead:Motor…………15 HPSpeed…………1,750 RPMWheel Size – Maximum…………16″ x 2″ x 5″Wheel Size – Throw away…………10″Travel…………16″Feedrate – Rapid…………400 IPMFootstock (Not Provided):Center taper…………Morse #5Quill Retraction…………1-1/2″Taper Adjustment on Tailstock – Eccentric…………0.006″
