24 Ton, 393” X 61” Turret Punch with Programmable Rotation of Tooling, Amada 160ES Punch and Die Sharpener, 4 - Station Multi Tool and Multi Head Tool Changing Post.
GENERAL SPECIFICATIONS Tonnage: 24 TonsY - Axis (Throat) w/ Multitool: 61”Y - Axis (Throat) w/ Single Tool: 59”X - Axis (Sheet Width): 98”X - Axis w/ Repositioning: Up to 393”Max Hit Rate 20mm Pitch: 375 SPMMax Hit Rate 1mm Pitch: 1000 SPMMax Hit Rate Scribing: 2000 SPMMax Sheet Weight: 440 LbsMain Motor: 11 HPFloor Space: 165” X 19”Weight: 19,900 LbsINCLUDES: Programmable Rotation of Tooling, Amada 160ES Punch and Die Sharpener, 4 - Station Multi Tool and Multi Head Tool Changing Post.
