Used Sistersville Tank Works Incorporated Shell and Tube Heat Exchanger. Approximately 745 square foot 316L stainless steel 20" diameter X 20' face to face length. 316L SS shell side rated 150 PSI @ 20 to 320 degrees F. (190) 3/4" 316L SS tubes rated 150 PSI @ 20 to 305 degrees F. 3" Process nozzles with 1" vent and drain. 3" service nozzles. NB# 3879, S/N: 06- 290. Built 2007. Weight 6150#. Missing one head
Used Equipment Facts About This Machine
Brand: Sistersville Tank Works Incorporated
National Board Number: 3879
Serial Number: 06-290
Year Built: 2007
Description:
This is a used shell and tube heat exchanger manufactured by Sistersville Tank Works. It features a 316L stainless steel shell and (190) 3/4" 316L stainless steel tubes, providing a total heat transfer area of approximately 745 square feet. The shell side is rated for 150 PSI at temperatures ranging from 20°F to 320°F, while the tube side is rated for 150 PSI at 20°F to 305°F. This unit has 3-inch process nozzles, 1-inch vent and drain ports, and 3-inch service nozzles. It weighs 6,150 lbs and is missing one head.
Specifications:
Total Heat Transfer Area: 745 sq. ft.
Shell Material: 316L Stainless Steel
Shell Size: 20" diameter x 20' length
Shell Pressure Rating: 150 PSI @ 20°F to 320°F
Tube Material: (190) 3/4" 316L Stainless Steel tubes
Tube Pressure Rating: 150 PSI @ 20°F to 305°F
Nozzle Connections:
(2) 3-inch process nozzles
(1) 1-inch vent and drain
(2) 3-inch service nozzles
Weight: 6,150 lbs
Missing Components: One head
Applications:
Chemical and pharmaceutical processing
Petrochemical and refinery operations
Food and beverage production
Steam heating and cooling systems
Heat recovery in industrial processes
Condensation and evaporation systems
Compatible Products & Systems:
Steam-to-liquid heat exchange systems
Industrial cooling and heating applications
Corrosive fluid processing equipment
High-pressure and high-temperature process systems
