Used Littleford Plow Mixer, Model FM-130D. 4.6 cubic foot total capacity; 2.8 cubic foot working capacity; Jacketed vacuum rated mixer. Stainless steel construction; Internal rated full vacuum; Jacket rated 75 PSI @ 320 degrees F; High speed chopper driven by 10 HP motor, 208-230/460V, 3500 rpm motor; 7.5 HP, 230/460V, 1740 rpm into Falk gear box with 8.908:1 reducer main drive; Has top-mounted liquid addition spray nozzle with Teel vane pump; Mounted on base. Jacket Serial# 13394. Serial# 42658-20656-5068.
USED EQUIPMENT FACTS ABOUT THIS MACHINE
Description
The Littleford FM-130D Plow Mixer is a high-performance, jacketed vacuum-rated mixing system, designed for high-shear blending, coating, and granulation of powders, pastes, and viscous materials. Constructed from stainless steel, this mixer ensures durability, corrosion resistance, and sanitary processing capabilities.
With a total capacity of 4.6 cubic feet and a working capacity of 2.8 cubic feet, this unit is ideal for small to medium-scale industrial mixing applications. It features an internally rated full vacuum chamber, allowing for dehydration, drying, and controlled atmospheric processing. The jacket is rated for 75 PSI at 320°F, enabling precise thermal control for temperature-sensitive formulations.
The system includes a high-speed chopper, powered by a 10 HP, 208-230/460V, 3500 RPM motor, providing efficient dispersion of agglomerates and uniform particle distribution. The main drive motor (7.5 HP, 230/460V, 1740 RPM) is connected to a Falk gearbox with an 8.908:1 reducer, delivering consistent torque and power for heavy-duty mixing applications.
Additional features include a top-mounted liquid addition spray nozzle, paired with a Teel vane pump, allowing for precise liquid dispersion during the mixing process. The entire system is mounted on a sturdy base, ensuring stability and operational efficiency.
Specifications
Total Capacity: 4.6 Cubic Feet
Working Capacity: 2.8 Cubic Feet
Material: Stainless Steel
Vacuum Rating: Full Vacuum Rated Chamber
Jacket Rating: 75 PSI @ 320°F
High-Speed Chopper:
Motor Power: 10 HP
Voltage: 208-230/460V
Speed: 3500 RPM
Main Drive System:
Motor Power: 7.5 HP
Voltage: 230/460V
Speed: 1740 RPM
Gearbox: Falk 8.908:1 Reducer
Liquid Addition System:
Top-Mounted Spray Nozzle
Teel Vane Pump
Mounting: Base Mounted
Condition: Used
Applications
Chemical Processing: Powder coating, granulation, and specialty chemical blending
Food & Beverage Processing: Spice mixing, dough conditioning, and flavor blending
Pharmaceutical & Nutraceutical: Granulation, encapsulation, and tablet formulation
Plastics & Composites: Polymer mixing, resin blending, and additive incorporation
Agricultural & Animal Feed: Fertilizer formulation and feed premix blending
Compatible Products & Uses
Vacuum Drying & Dehydration of Powders
High-Shear Mixing & Particle Size Reduction
Thermal Processing & Coating of Particulates
Liquid Incorporation & Homogeneous Blending
Industrial Powder & Granule Processing
