Used De Dietrich Glass Lined Reactor, 670 Liter (177 Gallon), 3008 Glass, Horizontal. Approximate 28 diameter x 60 straight side. Dished ends, (1) removable. Internal rated -1 to 6 bar (-14.5 to 87 psi) at -10 to 200 degrees C. (14 to 392 F.), carbon steel jacket rated 6/8 bar (87 to 116 psi) at -10 to 200 degrees C. (14 to 392 F.). Openings top (3) 4, 10. 2 End bottom outlet. Mounted on removable wood saddles with a carbon steel cart with casters.
Used Equipment Facts About This Machine
Manufacturer Information:
Brand: De Dietrich
Type: Glass-Lined Reactor
Model: 3008 Glass
Capacity: 670 Liters (177 Gallons)
Description:
This used De Dietrich 670L Glass-Lined Reactor is a high-quality chemical processing vessel, designed for corrosion-resistant applications in pharmaceutical, chemical, and industrial manufacturing.
Constructed with 3008 glass lining, this reactor offers superior resistance to acids, solvents, and high temperatures. The horizontal orientation and removable dished end provide easy access for cleaning and maintenance.
The reactor is rated for -1 to 6 bar (-14.5 to 87 psi) of internal pressure at -10 to 200°C (14 to 392°F), ensuring safe operation under demanding conditions. The carbon steel jacket is rated 6/8 bar (87 to 116 psi) at the same temperature range, allowing precise thermal regulation for controlled reactions.
It features:
(3) Top Openings (4", 10") for material addition and monitoring
2” End Bottom Outlet for controlled discharge
Mounted on Removable Wood Saddles
Carbon Steel Cart with Casters for mobility and flexibility
Specifications:
Capacity: 670 Liters (177 Gallons)
Construction: Glass-Lined (3008 Glass)
Orientation: Horizontal
Vessel Dimensions: 28” Diameter x 60” Straight Side
Ends: Dished (1 Removable)
Internal Pressure Rating: -1 to 6 bar (-14.5 to 87 psi)
Internal Temperature Rating: -10 to 200°C (14 to 392°F)
Jacket Material: Carbon Steel
Jacket Pressure Rating: 6/8 bar (87 to 116 psi)
Jacket Temperature Rating: -10 to 200°C (14 to 392°F)
Openings:
(3) Top Openings (4", 10")
2” End Bottom Outlet
Mounting: Removable Wood Saddles & Carbon Steel Cart with Casters
Applications:
Pharmaceutical & Biotech – Reaction vessel for API synthesis and chemical blending
Chemical Processing – Acid-resistant reactor for specialty chemicals and coatings
Food & Beverage – Processing of food-grade ingredients under controlled conditions
Petrochemical & Industrial Manufacturing – Corrosion-resistant reactor for high-temperature reactions
Research & Development – Laboratory-scale and pilot plant production of specialty compounds
What Products Would This Be Used For?
API (Active Pharmaceutical Ingredient) production
Specialty chemical synthesis
Corrosive acid and solvent reactions
Polymer and resin manufacturing
Heat-sensitive industrial formulations
