Unused- Criveller Company Model 7.5BBL, Approximate 150 Gallons (567 Liter) 304 Stainless Steel Jacketed Tank, Vertical. Approximate 37.4" diameter x 27.56" straight side, dished top & bottom. Internal rated 14.5/36 psi at -40 degrees F. Sidewall Dimple jacket rated 36 psi at -40 degrees F. Opening top: 6" agitator, 6", (3) 2", (1) 1", side: oval manway. 3" Center bottom outlet, approximate 17.75" discharge height. Insulated and sheathed. Mounted on 4 legs. Built 2019.
USED EQUIPMENT FACTS ABOUT THIS MACHINE
Information:
Manufacturer: Criveller Company
Model: 7.5BBL
Type: Jacketed Tank
Capacity: Approximately 150 Gallons (567 Liters)
Material: 304 Stainless Steel
Orientation: Vertical
Dimensions: Approximate 37.4" diameter x 27.56" straight side, dished top & bottom
Pressure Ratings:
Internal: 14.5/36 psi at -40 degrees F
Jacket: 36 psi at -40 degrees F
Jacket: Sidewall Dimple Jacket
Openings:
Top: 6" agitator, 6", (3) 2", (1) 1"
Side: Oval manway
Bottom: 3" Center bottom outlet, approximate 17.75" discharge height
Insulation: Insulated and sheathed
Mounting: Mounted on 4 legs
Build Date: Built 2019
Applications (Based on the description):
Pharmaceutical: Mixing and processing of various pharmaceutical ingredients and products.
Chemical Processing: Mixing and handling of chemicals that may require low-temperature processing.
Food Processing: Some specialized food processing applications may be suitable, but the -40°F temperature rating suggests it might be more suited for colder environments.
