MODEL ....................... 1000 U
SWING OVER TABLE ............ 10-1/4"
CENTER DISTANCE.............. 36"
WORKING SURFACE OF TABLE .... 62-5/8" X 5-1/2"
LONGTUDINAL TABLE TRVEL ..... 51-13/16"
STANDARD GRINDING WHEEL ..... 16" X 2" X 5"
WHEEL SPEED.................. 3600 RPM
WHEEL SLIDE MOVEMENT ........ 11-1/4"
WORK HEAD SPEEDS .............20 TO 400 RPM
HANDLE FEED ONE REVOLUTION... 0.005
INFEED PER TABLE RECERSAL ... 0.036
PLUNG GRINDING .............. 0.118 TO 0.05
WORKHEAD SPINDLE ROTATION ... 360 DEG SWIVEL
CENTER....................... NO. 3
COOLANT ..................... YES
GRINDING WHEEL MOTOR ........ 4 HORSEPOWER
WORK HEAD MOTOR ............. 1.2 HORSEPOWER
BrandKELLENBERGER
TypeGrinders, Cylindrical (Incl Plain & Angle Head)
Stock No.22404
