SERIAL ..................... 41192257
MODEL ...................... S-20P
YEAR NEW ................... 1992
SEMI AUTOMATIC ............. YES
CAPACITY ................... 13" X 18"
ROUND ...................... 13"
MITERING ................... 90 TO 60 DEGREES
CAPACITY AT 45 DEGREES ..... 13" X 10-3/4"
ROUND AT 45 DEGREES ........ 12"
CAPACITY AT 30 DEGREES ..... 13" X 7-3/4"
ROUND AT 30 DEGREES ........ 8-1/2"
BLADE SIZE ................. 1" X 14'10"
BLADE SPEED ................ 45 TO 330 SFM
COOLANT TANK CAPACITY ...... 6 US GALLONS
WORK LOAD .................. 5,000 LBS
TABLE HEIGHT ............... 31"
BLADE DRIVE ................ 3 HORSEPOWER
