SERIAL ............................ 10420-0072
MODEL ............................. NC1-200(2)
CAPACITY .......................... 220 TON
STROKE OF SLIDE ................... 12.59"
SLIDE ADJUSTMENT .................. 4.33"
POWER SLIDE ADJUSTMENT ............ YES
SHUT HEIGHT, OVER BOLSTER ......... 19.68"
AREA OF BED ....................... 54.7" X 33.0"
AREA OF RAM ....................... 34.6" X 25.5"
STROKES PER MINUTE ................ 25-45 SPM
AIR CLUTCH ........................ YES
AIR BRAKE ......................... YES
AIR COUNTER BALANCES .............. YES
HYDRAULIC OVERLAD PROTECTION ...... YES
FLOOR STANDING .................... YES
MOTOR ............................. 30 HP
