SERIAL ........................ 7856-69
BASE AREA ..................... 36" X 46"
SPINDLE SPEEDS ................ (12) 30 TO 1,500 RPM
FEEDS ......................... (6) .004 TO .025 IPR
SPINDLE TRAVEL ................ 12"
TAPER IN SPINDLE .............. #4 MT
DIAMETER OF SPINDLE ........... 2-1/2"
DISTANCE SPINDLE TO COLUMN .... 11" TO 36" MAXIMUM
DISTANCE SPINDLE TO BASE ...... 17" TO 55-1/4" MAXIMUM
TRAVEL OF HEAD ARM ............ 25-1/4"
TRAVEL OF ARM ON COLUMN ....... 28-1/2"
POWER ELEVATION ............... YES
POWER COLUMN CLAMPING ......... YES
COOLANT ....................... YES
MOTOR ......................... 5 HORSEPOWER
