MODEL #DV-59/DSM-59
MODEL
#DV-59/DSM-59
SWING OVER BED: 9″BED LENGTH: 28″COLLET CAPACITY: 1 1/16” 5-C ROUND COLLETSSPINDLE TAPER: HARDINGE TAPERSPINDLE SPEEDS: (8) 230 TO 3900 RPMTRAVEL OF CROSS SLIDE: 3-3/4″TRAVEL OF TURRET SLIDE: 4″DIAMETER OF TURRET HOLES: (5) 5/8″, (1) 1″MOTOR (2-SPEED): 1 HPSUPER PRECISION SPINDLE BEARINGSLEVER OPERATED 5-C COLLET CLOSERDOUBLE CUT-OFF SLIDEHARDINGE CABINET STAND
SWING OVER BED: 9″
BED LENGTH: 28″
COLLET CAPACITY: 1 1/16” 5-C ROUND COLLETS
SPINDLE TAPER: HARDINGE TAPER
SPINDLE SPEEDS: (8) 230 TO 3900 RPM
TRAVEL OF CROSS SLIDE: 3-3/4″
TRAVEL OF TURRET SLIDE: 4″
DIAMETER OF TURRET HOLES: (5) 5/8″, (1) 1″
MOTOR (2-SPEED): 1 HP
SUPER PRECISION SPINDLE BEARINGS
LEVER OPERATED 5-C COLLET CLOSER
DOUBLE CUT-OFF SLIDE
HARDINGE CABINET STAND
BrandHARDINGE
TypeLathes, Engine
Stock No.21133
