MODEL TRADEMASTER
MODEL TRADEMASTER
DAKE ORDER NUMBER .............. 88071
DAKE ORDER NUMBER .............. 88071
BLADE WIDTH .................... 1/4 - 1"
BLADE WIDTH .................... 1/4 - 1"
BLADE LENGTH ................... 150"
BLADE LENGTH ................... 150"
BLADE SPEED .................... 50 TO 500
BLADE SPEED .................... 50 TO 500
WORKTABLE TRAVEL DISTANCE ...... 11"
WORKTABLE TRAVEL DISTANCE ...... 11"
BAND WHEELS NUMBER ............. 2
BAND WHEELS NUMBER ............. 2
BAND WHEELS SIZE ............... 20
BAND WHEELS SIZE ............... 20
HORSEPOWER ..................... 1-1/2
HORSEPOWER ..................... 1-1/2
THROAT SIZE (BAND TO COLUMN) ... 19-1/2" (A)
THROAT SIZE (BAND TO COLUMN) ... 19-1/2" (A)
WORK HEIGHT .................... 12" (B)
WORK HEIGHT .................... 12" (B)
WORK TABLE DIMENSIONS .......... 24 X 24" (CxD)
WORK TABLE DIMENSIONS .......... 24 X 24" (CxD)
WORKTABLE TILT ................. 10º / 45º (ExF)
WORKTABLE TILT ................. 10º / 45º (ExF)
WORKTABLE HEIGHT ............... 41" (G)
WORKTABLE HEIGHT ............... 41" (G)
MACHINE HEIGHT ................. 80" (H)
MACHINE HEIGHT ................. 80" (H)
MACHINE FLOOR SPACE ............ 40 X 32" (JxK)
MACHINE FLOOR SPACE ............ 40 X 32" (JxK)
Specifications
