SERIAL ................................ 272-68155
MODEL ................................. 3612-H
THROAT BAND TO COLUMN.................. 35-1/2"
MAXIMUM WORK HEIGHT.................... 12"
BAND WIDTH CAPACITY.................... 1/16" TO 1"
BAND LENGTH:
2 WHEELS............................... 125"
3 WHEELS............................... 174"
TABLE SIZE OF FRONT TABLE.............. 24" X 30-1/2"
TABLE SIZE OF REAR TABLE............... 16-3/4" X 20-1/4"
VARIABLE SPEED DRIVE, INF. VARIABLE.... 50 to 5200 FPM
TABLE TILT............................. 45 DEG. RIGHT/10 DEG./LEFT
DRIVE MOTOR ........................... 2 HP
Specifications
