Die Set Capacity .................... 36” x 42” x 5 1/2” Max.
Die Set Thickness ................... 25” Max.
Quill Travel ........................ 6 ½”
Cross Travel of Drill Head .......... 36”
Longitudinal Travel of Drill Head ... 49”
Daylight Opening .................... 26 – ¾”
Drill Diameter ...................... 1” Max.
Variable Spindle Speeds ............. 200 to 1850 RPM,
Power Elevation ..................... 4 IPM
1 HP 220/440/3 Spindle Motor & Controls
3 HP 220/440/3 Elevating Motor & Controls
Equipped with:
Drill Chuck
Drilling Head
Indexing Slide Heads
