SERIAL ......................... B0298158H
MODEL .......................... H-16
YEAR NEW ....................... 1998
CAPACITY SQUARES ............... 16" X 16"
CAPACITY ROUNDS ................ 16"
BLADE SPEEDS (VARIABLE) ........ 50 TO 350 SFPM
BLADE SIZE ..................... 18'10" X 1-1/2"
MAXIMUM WORK LOAD .............. 10,000 LBS.
SHUTTLE STROKE ................. 0 TO 39"
BUNDLING / NESTING FEATURE ..... HYDRAULIC
SHUTTLE VISES ..................
HYDRAULIC
FEED PRESSURE .................. 0 TO 400 PSI
CONTROLS ....................... PLC 100
POWER BLADE BRUSH .............. YES
CONTROLS ....................... PLC 100
POWER BLADE BRUSH .............. YES
BLADE TENSIONING ............... YES
CHIP AUGER CONVEYOR ............ YES
OPERATOR'S CONSOLE STATION ..... YES
DIGITAL ANGLE DISPLAY .......... YES
COOLANT ........................ YES
BLADE DRIVE MOTER .............. 10 HORSEPOWER
HYDRAULIC MOTOR ................ 3
HP/480V/60CY/3PH
