MODEL ................ 20060N
TONNAGE CAPACITY ..... 200 TON
STROKE ............... 15"
CYLINDER DIAMETER .... 12"
PRESS PLATEN SIZE .... 61" WIDE X 14-1/2" HIGH
PRESS PLATEN WIDTH ... 18"
PLATEN T-SLOTTED ..... YES, 3 T-SLOTS
BED SIZE ............. 60" F-B X 77" L-R
RE
SISTANCE PIN ....... 10" DIAMETER
FLOOR TO BED ......... 30"
PULL BACK CYLINDERS .. (2) ON SIDE OF RAM
CONTROLS ............. FOOT PEDALS
PRESSURE GUAGE ....... YES
E-STOP BUTTON ........ YES
OILGEAR HYD PUMP ..... DH-3525
MOTOR ................ 75 HP
