SERIAL ...................... HP52840
MODEL ....................... 3-3/4 B
YEAR ........................ 1981
SLIDE PLUNGER CAPACITY ...... 150 TON
BLANKHOLDER CAPACITY ........ 110 TON
SLIDE PLUNGER STROKE ........ 20"
SLIDE PLUNGER SHUT HEIGHT ... 22 to 26"
BLANKHOLDER STROKE .......... 11-1/2"
BLANKHOLDER SHUT HEIGHT ..... 20" to 24"
ADJUSTMENTS ................. 4"
RUN MODES ................... INCH, SINGLE, CONT
PROGRAMMABLE RUN MODE ....... YES
UPDATED CONTROLS ............ ROCKFORD SSC-1550
RUN MODES ................... PROGRAM, SINGLE & CONTINUOUS
FORWARD & REVERSE ........... YES
HAND & FOOT TRIP ............ YES
LIGHT CURTAINS .............. YES
KNOCKOUT EJECTOR ............ YES
AIR CLUTCH .................. YES
LUBE SYSTEM ................. YES
E-STOP BUTTON ............... YES
FLOOR STANDING .............. YES
MOTOR ....................... 15 HP
