SERIAL .......................... 295
MODEL ........................... F-16-2A TWIN POST
CAPACITY (RECTANGULAR @ 90°) .... 16″H X 20″W
CAPACITY (ROUND @ 90°) .......... 16″ DIAMETER
WEIGHT CAPACITY ................. 5,000 LBS
BLADE SPEED ..................... 60 TO 425 SFPM
BLADE SIZE ...................... 1¼” X .042″ X 15′
BLADE GUIDE ..................... ROLLERS & CARBIDE SIDE BLOCKS
BLADE TENSION ................... HYDRAULIC
BAND WHEEL SIZE ................. 20″
VISE (FULL STROKE HYDRAULIC) .... 8-1/2”
AC VECTOR BLADE DRIVE ........... 7½ HP
SAWING FORCE ....................
0 TO 750 LBS
COOLANT CAPACITY ................ 15 GALLONS
HYDRAULIC CAPACITY .............. 20 GALLONS
WORK HEIGHT ..................... 26″
CONVEYOR ........................ 18"W
HYDRAULIC DRIVE MOTOR ........... 2 HP
Specifications
