SERIAL ................ 48944
MODEL ................. BP2-500-60-42
CAPACITY............... 500 TONS
STROKE ................ 6"
SHUT HEIGHT(SDAU) ..... 38"
ADJUSTMENT (POWER) .... 15"
SPEED ................. 30 TO 60 SPM
AREA OF BED & RAM ..... 60" X 42"
RAM BOLSTER SIZE ...... 60" X 42"
BED BOLSTER SIZE ...... 60" X 42"
BOLSTER THICKNESS ..... 8" THICK
WINDOW AREA (W X H) ... 35" X 30"
FLOOR TO BED .......... 42"
RUN MODES ............. JOG, SINGLE, CONTINUOUS
AIR CLUTCH ............ YES
AIR COUNTERBALANCES ... YES
SINGLE BACK GEARED .... YES
PEDESTAL CONTROLS ..... YES
FLOOR STANDING ........ NO PIT REQUIRED
OVERALL HEIGHT ........ 232"
