SERIAL 3157 101 006
MODEL GKS 400AU
NEW 1993
SERIAL 3157 101 006
MODEL GKS 400AU
NEW 1993
SERIAL 3157 101 006
MODEL GKS 400AU
NEW 1993
Saw Blade Diameter: 15.74" (400 mm)
Cutting Diameter: 5.11" (130 mm)
ROUND @ 45 Degree: 5.11" (130 mm)
FLAT @ 45 Degree: 6.29" x 35.0" (160 x 890 mm)
ROUND @ 90 Degree: 5.11" (130 mm)
FLAT @ 90 Degree: 8.26" x 3.14" (210 x 80 mm)
ROUND @ 60 Degree: 3.54" (90 mm)
FLAT @ 60 Degree ....... 4.13" x 3.14" (105 x 80 mm)
Saw Blade Feeds-Speeds: 629" TO 23.6" in/min (16-600 mm/min)
Saw Blade Diameter (max.): 16.73" (425 mm)
Table Rotation: 150 Degree
Feed Length: 47.2" (1200 mm)
Multiple/Combined Feed Length: 141.7" (3600 mm)
Blade Motor: 2.14/3.35 HP (1.6/2.5 Kw)
ROLL GUIDEWAYS w/LENGTH STOP: YES
Specifications
