16" HEALD MODEL #271 INTERNAL GRINDER: STOCK #17351
SERIAL ................................ 271-TR-62083
MODEL ................................. 271 (PLAIN)
SWING OVER TABLE ...................... 18"
SWING INSIDE COOLANT GUARD ............ 12"
LENGTH OF HOLE THAT CAN BE GROUND ..... 8"
DIAMETER OF HOLE THAT CAN BE GROUND ... 8-3/4"
MAXIMUM INCLUDED ANGLE TAPER .......... 60 DEGREES
HOLE THROUGH WORKHEAD SPINDLE ......... 2"
TABLE TRAVEL .......................... 16"
RAPID TRAVERSE ........................ 35 FPM
GRINDING SPEED ........................ 0 TO 20 FPM
WORKHEAD SPEEDS ....................... 133, 200, 266, 400 RPM
REDHEAD SPINDLE ....................... YES
MOTORS ................................ 5 HORSEPOWER
Specifications
