SERIAL ....................... 54181
MODEL ........................ B130
SPINDLE DIAMETER ............. 5-1/8"
SPINDLE TAPER ................ #50
SPINDLE QUILL TRAVEL ......... 40"
SPINDLE QUILL TRAVEL ......... 40"
SPINDLE SPEEDS ............... (21) 14 TO 1,000 RPM
SPINDLE FEEDS ................ (27) .03 TO 12 mm/r
ROTARY TABLE SIZE ............ 48" X 56"
ROTARY TABLE T-SLOTTED ....... YES
ROTARY TABLE ROTATION ........ POWERED 360 DEGREES
ROTARY TABLE WEIGHT CAPACITY . 15,000 LBS
VERTICAL HEAD TRAVEL ......... 48"
TABLE CROSS TRAVEL ........... 72"
LONGINTUDINAL SADDLE TRAVEL .. 77"
RAPID TRAVERSE ............... YES, ALL DIRECTIONS
PENDANT CONTROL .............. YES
MOTOR ........................ 20 HP
