SERIAL ....................... 5255MODEL ........................ 912MAX TUBE DIAMETER ............ 3"MIN TUBE DIAMETER ............ 1/2"MAX WALL THICKNESS ........... 0.120"MIN WALL THICKNESS ........... 0.28"LENGTH ....................... 6" - 78"FEED ......................... ADJUSTABLE, ELECTRICPOWER ........................ 440-460 VAC/60 HZ/ 40 AMPPNEUMATIC .................... 80 PSI-4 BARPRODUCTION RATE .............. 500-3,000 PARTS PER HOURLENGTH TOLERANCE ............. +/- .005"LENGTH READOUT ............... DIGITAL IN INCHES & MMSPINDLE DRIVES ............... (2)MOTORS @ 7.5 HPTUBE FINISH I.D. CHAMFER ..... 30 DEGREESTUBE FINISH O.D. CHAMFER ..... 30 DEGREESCUTTERS:DEDICATED CARBIDE INSERTED NC TYPE CUTTERSQUICK CHANGE TOOLINGADJUSTABLE CARBIDE INSERTED CUTTEREND FACE FLAT & SQUARE TO CENTER LINE OF TUBE
SERIAL ....................... 5255
MODEL ........................ 912
MAX TUBE DIAMETER ............ 3"
MIN TUBE DIAMETER ............ 1/2"
MAX WALL THICKNESS ........... 0.120"
MIN WALL THICKNESS ........... 0.28"
LENGTH ....................... 6" - 78"
FEED ......................... ADJUSTABLE, ELECTRIC
POWER ........................ 440-460 VAC/60 HZ/ 40 AMP
PNEUMATIC .................... 80 PSI-4 BAR
PRODUCTION RATE .............. 500-3,000 PARTS PER HOUR
LENGTH TOLERANCE ............. +/- .005"
LENGTH READOUT ............... DIGITAL IN INCHES & MM
SPINDLE DRIVES ............... (2)MOTORS @ 7.5 HP
TUBE FINISH I.D. CHAMFER ..... 30 DEGREES
TUBE FINISH O.D. CHAMFER ..... 30 DEGREES
CUTTERS:
DEDICATED CARBIDE INSERTED NC TYPE CUTTERS
QUICK CHANGE TOOLING
ADJUSTABLE CARBIDE INSERTED CUTTER
END FACE FLAT & SQUARE TO CENTER LINE OF TUBE
Specifications
BrandHAVEN
TypeChamfering Machines
Stock No.15806
