CAPACITY ..................... 1000 TONS
BED LENGTH ................... 96"
BED WIDTH .................... 48"
DISTANCE BETWEEN COLUMNS ..... 72"
STROKE ....................... 42"
RAM SPEED (RAPID ADVANCE) .... 360" PER MINUTE
RAM SPEED (PRESSING SPEED) ... 14" PER MINUTE
DAYLIGHT (BOLTER TO PLATEN) .. 42" MAX
DAYLIGHT (BED TO PLATEN) ..... 51.75" MAX
BOLSTER THICKNESS ............ 9.75"
BOLSTER WITH T SLOTS ......... YES, 4" CENTERS
RAM PLATEN WITH HOLES ........ (200) 3/4" DIAMETER
PUMP ......................... DH-6025
HYDRO PNEUMATIC CUSHION ...... 250 TON
DIE CUSHION PAD .............. 59" X 36"
STROKE OF DIE CUSHION ........ 14"
Specifications
