SERIAL .................................. 26382
MODEL ................................... B-30
MAX WIDTH CAPACITY ...................... 30"
MAX THICKNESS CAPACITY @ FULL WIDTH ..... 0.065"
MAX THICKNESS CAPACITY .................. .140"
STOCK THICKNESS CAPACITY ................ .065" @ 30" WIDE
STOCK THICKNESS CAPACITY ................ .140" @ 10" WIDE
ROWE EQUIPMENT & FEATURES:
NUMBER OF ROLLS ........................ 7
DIAMETER OF ROLLS ...................... 2.75"
BANK STYLE UPPER ROLL ADJUSTMENTS ...... YES
DUAL UPPER ROLL ADJ HANDLES ............ YES
ENTRY & EXIT PINCH ROLLS ............... 2.75" DIAMETER
AIR OPERATED UPPER PINCH ROLL ADJ ...... YES
ADJUSTABLE STOCK WIDTH EDGE GUIDES ..... YES
INCLINED CABINET ....................... YES
CASCADE LOOP SUPPORT ROLLERS ........... YES
VARI SPEED PAYOUT ...................... YES
OPERATOS CONTROL CONSOLE ............... YES
Specifications
