GEMINIS ENGINE LATHE
SERIAL ...................... N2750 HB450
MODEL ....................... GE870
SWING OVER BED .............. 40"
SWING OVER CROSS SLIDE ...... 29"
SWING IN THE GAP ............ 50"
LENGTH OF GAP ............... 12"
DISTANCE BETWEEN CENTERS .... 72"
SPEEDS ...................... (18) 16 TO 1250 RPM
FEEDS ....................... (48) .0016" - .0942" IPR
THREADS ..................... (48) 2 - 112 TPI
SPINDLE HOLE ................ 3-1/4"
CHUCK ....................... 25" 3-JAW
THREADING CHASE DIAL ........ YES
TOOL POST HOLDER ............ YES
E-STOP ...................... YES
MOTOR ....................... 16 HP
FEEDS ....................... (48) .0016" - .0942" IPR
THREADS ..................... (48) 2 - 112 TPI
Specifications
