SERIAL ......................... C14-23-102
CMMA CLASS ..................... "E" INDOOR
BRIDGE:
SPAN ............................ 82'
SPEED ........................... 0 TO 300 FPM (2) @40 HP
DRIVE TYPE ...................... A-4
WHEEL DIA ....................... (4) @24"
RAIL SIZE ....................... ASCE 171#
GIRDER TYPE ..................... FABRICATED BOX
HOIST MAIN
CAPACITY ...................... 100 TON (200,000 LBS)
LIFT .......................... 115'
HOIST SPEED ................... 21/32 FPM (1) @ 150 HP
HOIST AUXILIARY
CAPACITY ...................... 44 TON (88,000 LBS)
LIFT .......................... 115'
HOIST SPEED ................... 50/75 FPM @ (1) 150 HP
TROLLEY:
SPEED ......................... 0 TO 160 FPM (1) @40 HP
DRIVE TYPE .................... A-1
WHEEL DIA ..................... (4) @ 21"
RAIL SIZE ..................... A5CE @ 5#
INCOMING VOLTAGE .............. 460/3/60
TOTAL CRANE WEIGHT ............ 200,000 LBS
CONDITION: EXCELLENT
C14-23-102
Specifications
