SERIAL ............................... 9605
MODEL ................................ 2ST CRFM
DIRECTION OF TRAVEL .................. R-L
NUMBER OF DRIVE HOUSINGS ............. 10
SHAFT DIAMETER ....................... 2.5"
ROLL SPACE ........................... 21.375"
KEYWAY WIDTH ......................... 0.360"
KEYWAY DEPTH ......................... 0.198"
ROLL SHAFT RATIOS (BOTTOM TO TOP) .... EQUAL
VERTICAL SHAFT CENTERS ............... 5" TO 7.5"
HORIZONTAL SHAFT CENTERS ............. 15"
CENTERLINE BOTTOM SHAFT TO TOP BASE .. 9.25"
TOP OF BASE TO FLOOR ................. 30"
CONTROLS ............................. YES
COOLANT .............................. YES
MOTOR ................................ 25 HP
Brand
KANE & ROACH
Type
Roll Formers
Stock No.
11366
