SERIAL ......................... A 65 M 746
MODEL .......................... RU-12-9-DT
YEAR ........................... 2008
TOOL STROKE .................... 8.66"
END FORMING PRESSURE ........... 18 LBS
CLAMPING FORCE FOR WORKPIECE ... 40,000 LBS
POSITIONAL ACCURACY............. +/-0,01 MM
REPEATABILITY .................. <0,01 MM
MAX END FORMING SPEED .......... 12"/SEC
MIN END FORMING SPEED .......... 7"/SEC
ELECTRICAL CONNECTION .......... 3X400V / 50HZ FUSED WITH 16A
CONTROL VOLTAGE ................ 24 VDC
PNEUMATIC CONNECTION ........... 100 PSI
CLAMPING JAWS/HORIZONTAL ....... OPTIONAL
CLAMPING JAWS/VERTICAL ......... OTPIONAL
FORMING STAMP .................. 2, 6 OR 8
MOTOR .......................... 400V/50/60HZ/5KVA
Specifications
