MITSUBISHI M-H60EN Horizontal Machining Center, 40 hp, 6,000 RPM, CAT 50 taper, 80 ATC. Travel: 39.4" x 31.5" x 31.5". Pallet: 24.75" x 24.75". Ideal for manufacturers seeking reliable and robust used machinery.
| X | 39.4" | 1,000.8 mm |
| Y | 31.5" | 800.1 mm |
| Z | 31.5" | 800.1 mm |
| Power | 40 hp | 29.8 kW |
| RPM | 6,000 RPM | 6,000 RPM |
| # ATC | 80 | 80 |
| Taper | Cat 50 | Cat 50 |
| Pallet-W | 24.75" | 628.65 mm |
| Pallet-L | 24.75" | 628.65 mm |
Model: M-H60EN
Year of manufacture: 2000
35/40 HP High Performance Horizontal Machining Center w/ APC and Opt B-Axis Rotary Table
Machine Type: Machining Center
Num. of Axes: 3
Operation Type: CNC
CNC Brand: Meldas 610
CNC Brand Opt: Fanuc 18iM
Table/Work Support
Table Size L x W (in.): 24.800(L) x 24.800(W)
Max Workpiece Weight (lbs): 2,640
Support Index Table: Standard
Support Rotary Table: Optional
Spindle(s)
Direction: Horizontal
Taper: # 50
Top RPM: 6,000
Top RPM Opt: 12,000
HP (30 min rating): 35.00
HP Opt: 40.00
Tooling
Tool Carrier: ATC
Num. Tools: 40
Num. Tools Opt: 120
Tool Change Time (sec): 4.00
Tool Change Chip Time (sec): 8.00
Pallet Changer Available: Standard
Num. Pallets: 2
Num. Pallets Opt: 10
Axes And Travels
Num. Axes: 3
Num. Axes Opt: 4
U Axis: None
Travel Max Feed Rate Rapid Traverse
X1 39.400" 1,575 1,575ipm
Y1 31.500" 1,575 1,575ipm
Z1 31.500" 1,575 1,575ipm
B1 360.000°
Features:
Dual pallet shuttle system
Manual pulse generator
Mitsubishi Meldas controls
Equipt with:
Coolant system with chip conveyor
This machine is under power for inspection.
