USED 2017 CLAUSING COLCHESTER 8044VSJ

CLAUSING COLCHESTER 15”/23” x 50”cc Variable Speed Lathe 2017’ #7448

CLAUSING COLCHESTER 15”/23” x 50”cc Variable Speed Lathe 2017’ #7448
Model # 8044VSJ
Serial # SG3046
Year of manufacture : 2017
Swing over bed ways: 15.75”
Swing in gap: 23"
Swing over cross slide: 9.7"
Bedway width: 12.5"
Spindle bore: 2.12"
Spindle nose: D1-6 Camlock
Spindle nose taper: #4 Morse
Number of speed ranges: (3) infinitely variable
Spindle speed ranges: 15 – 2500 R.P.M.
Low range: 15 – 300 R.P.M.
Mid range: 35 – 830 R.P.M.
High range: 110 – 2500 R.P.M.
Travel of cross slide: 9.8”
Width of cross slide: 7.09”
Travel of top slide: 5.1”
Width of top slide: 3.93”
Tailstock quill travel: 5.5"
Tailstock quill diameter: 2.87"
Tailstock quill taper: #5 Morse
Longitudinal feed range:
Inch: .014 - .048 Inch/rev
mm: .36 – 1.20 mm/rev
Cross feed range:
Inch: .00035 - .024 Inch/rev
mm: .0089 - .061 mm/rev
Number of inch pitches: 56
Range of inch pitches: 2 – 56 T.P.I.
Number of metric pitches: 51
Range of metric pitches: .2 – 14mm
Number of diametral pitches: 20
Range of diametral pitches: 8 - 56 DP
Number of module pitches: 20
Range of module pitches: .2 – 3.5 MOD

***Came out of a Laboratory***
2 Axis ACURITE DRO Digital Read Out with “CSS” Constant Surface Speed Option
Brand New BISON 10” 3 Jaw Chuck
ALORIS Tool Post
Live Center
Stead Rest
Coolant tank & Pump
Extra change gears
10 H.P. Spindle motor
Machine is wired for 460 volt / 3 phase / 60 H.Z.
Machine weight- 3500 Lbs.
Machine dimensions- 100” x 51” x 72” H
Machine location- F.O.B. Sarasota Florida
