JUST SOLD
| Capacity | 8,000 lb | 3,628.7 kg |
| Lift Height | 504" | 12,802 mm |
| Machine Hours | 3932 | 3932 |
Rated Capacity8,000 lb / 3,629 kg
Maximum Lift Height: 42 ft 4 in / 12.9 m
Load at Max Height: 6,000 lb / 2,722 kg
Maximum Forward Reach: 29 ft 6 in / 9.0 m
Load at Max Reach: 1,600 lb / 726 kg
Frame Leveling: 10 degrees
Lift Speed (Boom Retracted) Up: 15.5 sec
Lift Speed (Boom Retracted) Down: 12.3 sec
Boom Speed Extended: 14.6 sec
Boom Speed Retracted: 12 sec
Top Travel Speed (4-Speed):15 mph / 24.1 km/h
Drawbar Pull (Loaded):15,062 lb / 67 kN
Outside Turning Radius:12 ft 10 in / 3.9 m
Operating Weight: 21,200 lb / 9,616 kg
